DAF System
DAF System
The DAF system is used to separate solids from wastewater. It creates tiny air bubbles that attach to particles and lift them to the surface, where they can be easily removed. It works efficiently and produces clean water with low levels of suspended solids. The system is compact, runs automatically, and can be controlled with a single button. It also supports remote monitoring for easier operation. Its space-saving design and flexible capacity make it suitable for both industrial and municipal use. Overall, it’s a reliable and efficient solution for water treatment and purification.
| Model | Capacity (m³/h) | L (mm) | W (mm) | H (mm) | Net Wt (T) | Running Wt (T) | Total Power (kW) | Reflux Pump (kW) | Air Compressor (kW) | Skimmer (kW) | Mixer1 (kW) | Mixer2 (kW) | Material |
| AQT-DAF005 | 5 | 2800 | 1000 | 2100 | 3 | 8 | 4.75 | 3 | 0.55 | 0.1 | 0.55 | 0.55 | Carbon steel |
| AQT-DAF010 | 10 | 3200 | 1200 | 2200 | 4 | 12 | 4.75 | 3 | 0.55 | 0.1 | 0.55 | 0.55 | Carbon steel |
| AQT-DAF025 | 25 | 5000 | 1500 | 1350 | 5.5 | 21 | 5.85 | 3.7 | 0.75 | 0.1 | 0.75 | 0.75 | Carbon steel |
| AQT-DAF050 | 50 | 6500 | 2000 | 2500 | 7 | 36 | 9.05 | 5.5 | 1.5 | 0.2 | 1.1 | 1.1 | Carbon steel |
| AQT-DAF080 | 80 | 7600 | 2600 | 2600 | 9 | 55 | 11.05 | 7.5 | 1.5 | 0.2 | 1.1 | 0.75 | Carbon steel |
| AQT-DAF100 | 100 | 8300 | 3000 | 3000 | 12 | 70 | 16.2 | 7.5 | 2.2 | 0.4 | 1.5 | 1.1 | Carbon steel |
Features
Standard Features
- Bubble Size ≤10 µm for efficient flotation.
- Dissolved Gas Efficiency >95% for stable performance.
- Compact Structure requires less land area.
- Effluent SS <20 mg/L with proper treatment.
- One-Button Start & Unattended Operation for ease of use.
- Cloud Digital Service ready for remote supervision.
Options & Accessories
- Various Model Capacities from 5 to 100 m³/h.
- Carbon Steel Construction as standard (optional upgrades available).
Working Principle
The DAF system dissolves air into water under high pressure to create a supersaturated solution. When released into the flotation tank at atmospheric pressure, millions of microbubbles (≈20–50 µm) attach to suspended particles, lowering their density and lifting them to the surface. The floated sludge is skimmed off for further treatment, while clarified water is discharged or reused.
Key Benefits
- Ultra-Fine Bubbles: Bubble size ≤10 µm for superior solid-liquid separation.
- High Dissolved Gas Efficiency: Efficiency above 95% for reliable operation.
- Compact Footprint: Space-saving design with effluent SS <20 mg/L.
- Automated Operation: One-button starts with unattended operation.
- Cloud Digital Service: Remote monitoring and digital integration available.
Key Benefits
- Ultra-Fine Bubbles: Bubble size ≤10 µm for superior solid-liquid separation.
- High Dissolved Gas Efficiency: Efficiency above 95% for reliable operation.
- Compact Footprint: Space-saving design with effluent SS <20 mg/L.
- Automated Operation: One-button starts with unattended operation.
- Cloud Digital Service: Remote monitoring and digital integration available.
Working Principle
The DAF system dissolves air into water under high pressure to create a supersaturated solution. When released into the flotation tank at atmospheric pressure, millions of microbubbles (≈20–50 µm) attach to suspended particles, lowering their density and lifting them to the surface. The floated sludge is skimmed off for further treatment, while clarified water is discharged or reused.
Features
Standard Features
- Bubble Size ≤10 µm for efficient flotation.
- Dissolved Gas Efficiency >95% for stable performance.
- Compact Structure requires less land area.
- Effluent SS <20 mg/L with proper treatment.
- One-Button Start & Unattended Operation for ease of use.
- Cloud Digital Service ready for remote supervision.
Options & Accessories
- Various Model Capacities from 5 to 100 m³/h.
- Carbon Steel Construction as standard (optional upgrades available).
| Model | Capacity (m³/h) | L (mm) | W (mm) | H (mm) | Net Wt (T) | Running Wt (T) | Total Power (kW) | Reflux Pump (kW) | Air Compressor (kW) | Skimmer (kW) | Mixer1 (kW) | Mixer2 (kW) | Material |
| AQT-DAF005 | 5 | 2800 | 1000 | 2100 | 3 | 8 | 4.75 | 3 | 0.55 | 0.1 | 0.55 | 0.55 | Carbon steel |
| AQT-DAF010 | 10 | 3200 | 1200 | 2200 | 4 | 12 | 4.75 | 3 | 0.55 | 0.1 | 0.55 | 0.55 | Carbon steel |
| AQT-DAF025 | 25 | 5000 | 1500 | 1350 | 5.5 | 21 | 5.85 | 3.7 | 0.75 | 0.1 | 0.75 | 0.75 | Carbon steel |
| AQT-DAF050 | 50 | 6500 | 2000 | 2500 | 7 | 36 | 9.05 | 5.5 | 1.5 | 0.2 | 1.1 | 1.1 | Carbon steel |
| AQT-DAF080 | 80 | 7600 | 2600 | 2600 | 9 | 55 | 11.05 | 7.5 | 1.5 | 0.2 | 1.1 | 0.75 | Carbon steel |
| AQT-DAF100 | 100 | 8300 | 3000 | 3000 | 12 | 70 | 16.2 | 7.5 | 2.2 | 0.4 | 1.5 | 1.1 | Carbon steel |
