Drilling Fluid Decanter Centrifuge

Name: Drilling Fluid Decanter Centrifuge to Separate Fine Solids | AQUIPTEC
SKU: SKU_203-17

Solids Handling, Screening & Sludge Treatment Equipment

The decanter centrifuge is used to separate fine and very fine solids from the slurry. It spins at high speed, using centrifugal force to separate the materials. A screw conveyor pushes out solids, while clean liquid flows out separately. It helps improve drilling fluid quality, extend fluid life, and reduce waste and operating costs. With its compact design and wear-resistant parts, it is built for durability and easy integration into existing systems. It can also be customised with features such as variable-speed control to suit different conditions and project needs.

1. What is a decanter centrifuge?

A decanter centrifuge is a machine that separates solids from liquids using high-speed rotation, commonly used in drilling fluid treatment.

2. What are the benefits of using a decanter centrifuge?

It improves separation efficiency, extends drilling fluid life, reduces waste, and lowers operating costs.

3. What industries use decanter centrifuges?

They are widely used in oil and gas drilling, tunnelling, mining, and other slurry separation processes.

4. Can the centrifuge be customised for different projects?

Yes, parameters like speed, torque, and bowl design can be adjusted to suit different slurry conditions and project requirements.

Model	AQT-LW450x850 Middle-speed	AQT-LW600x1019D Middle-speed	AQT-LW700x1200D Middle-speed	AQT-LW450BSx1250D High-speed variable frequency	AQT-LW450BPx1250 High-speed variable frequency	AQT-GLW600BPx1200D High-speed variable frequency	AQT-LW450x1000D Middle-speed	AQT-LW355x1250D High-speed	AQT-LW455x1250D High-speed
Drum diameter	450mm	600mm	700mm	450mm	450mm	600mm	450mm	355mm	455mm
Drum Length	850mm	1019mm	1200mm	1250mm	1250mm	1500mm	1000mm	1250mm	1250mm
Drum Speed/rpm	1480rpm	1500rpm	1480rpm	2000-2600rpm	0-2800rpm	0-2600rpm	2000rpm	2600rpm	2800rpm
Main Motor Power	22kw-IV class	45kw-IV class	55kw-IV class	45kw-IV class	45kw-IV class	55kw-IV class	30kw-IV class	37kw-IV class	37kw-IV class
Back Motor power	5.5kw-IV class	7.5kw-IV class	22kw-IV class	11kw-IV class	11kw-IV class	11kw-IV class	7.5kw-IV class	11kw-IV class	11kw-IV class
Max treating capacity	40m3/h	60m3/h	90m3/h	60m3/h	60m3/h	90m3/h	50m3/h	50m3/h	50m3/h
Min Separation point	5-7um	3-7um	5-7um	3-7um	2-5um	2-5um	2-5um	2-5um	2-5um
Separation factor	548G	750G	852G	1690G	1960G	2253G	1000G	1333G	1982G
Dimension	2350x1480x1550mm	2900x1600x1950mm	3100X1700X1980	3100x1620x1890mm	2350x1480x1710mm	3200X1600X1750	2450x1600x1650mm	2900x1500x1650mm	2900X1500X1650
Weight	3000kg	3650kg	4300KG	3500kg	4000kg	4500KG	3000kg	2950kg	2950KG

Features

Standard Features

High-speed rotating bowl for efficient centrifugal separation
Screw conveyor (scroll) for continuous solids discharge
Differential speed control between bowl and scroll
Continuous operation for stable and reliable performance
Enclosed design for clean and safe operation
Wear-resistant components for extended service life
Compact structure for easy installation and integration

Options & Accessories

Variable frequency drive (VFD) for speed control
Different bowl sizes and configurations
Advanced control systems and monitoring sensors
Chemical dosing system for enhanced separation performance

Working Principle

The Decanter Centrifuge operates based on sedimentation under high centrifugal force. The slurry is fed into a rapidly rotating horizontal bowl, where centrifugal force causes denser solid particles to move outward and form a compact layer along the inner wall of the bowl. At the same time, the lighter liquid phase forms an inner layer and flows towards the liquid discharge outlet.

A screw conveyor (scroll), rotating at a slightly different speed from the bowl, continuously transports the settled solids towards the conical end of the centrifuge for discharge. The clarified liquid is discharged separately, allowing continuous separation and dewatering of the slurry.

Key Benefits

High-Efficiency Fine Solid Removal
Effectively removes ultra-fine particles from slurry while maintaining the required drilling fluid properties for stable operation.
Superior Separation Performance
Provides higher separation efficiency compared to conventional screening and cyclone systems, improving overall solids control performance.
Extended Fluid Lifecycle
Enhances reuse of drilling fluid by reducing contamination, helping to extend fluid life and maintain consistent process conditions.
Reduced Operating Costs
Minimises waste generation and reduces the need for fluid replacement, lowering overall operational and disposal costs.
Energy-Efficient Operation
High-speed centrifuge design delivers efficient separation with optimised energy consumption and reduced vibration levels.
Flexible System Integration
Designed for easy integration into existing solids control and mud recovery systems with minimal modification.
Customised Performance Optimisation
Operating parameters such as speed, torque, and bowl configuration can be adjusted to suit specific project requirements and slurry conditions
